Here you can download all impulse responses as fir files and all background noises as wav files. Depending on what you need, you can get all files in one zip folder or just the impulse responses and background noises of one car. The download is free, but we would appreciate if you notfied us that you are using the files and for which purpose. For this please contact Gerhard Schmidt. f you publish work based on this database, please also cite one of our corresponding publications.

Files Size Download
All
(includes everything)		 6800 MByte zip file
  V class Daimler
(includes all V class noises and impulse responses)		 6800 MByte zip file
    Noise files 6800 MByte zip file
    Impulse responses 15 MByte zip file

Here you can get an overview about the current state of the corpus. In the summary below all vehicles, in which measurements took place, are shown with tables giving information on what noise recordings and impulse responses are currently availably for that vehicle. At the moment only measurements from a Daimler V Class are available, but in the future other cars will be added to the corpus. In total, more than 1000 noise files and more than 600 impulse responses are currently available.

Below tables for the noise recordings summarize which noise conditions exist for a vehicle. For, e.g., the Daimler V Class noise conditions span a speed range of 0-200 km/h in combination with the fan speeds 1,4, and 7. All available combinations are listed and are assigned a condition number. Additionally, information on the number of channels/microphones, the number of files and recording sessions is given. Where applicable, remarks regarding special events or occurences are given as well.

The tables for the impulse responses give information on the total number of impulse responses. The tables are designed as matrices. They show all loudspeaker and microphone types of the vehicle and how many impulse responses are available for the pairings of loudspeaker and microphones types.

You can find more details and the results of the measurements in the sections "Background Noise" and "Impulse Responses". If you would like to know the exact numbers and positions of the microphones and loudspeakers, take a look at the sections "Microphones" and "Loudspeakers", respectively. All impulse responses and background noises can be downloaded here as fir files and wav files, respectively. On the same page you will also find example code to read the fir files with either Matlab or Python.



{tab-cars V Class (Daimler)}

Noise Recordings

Speed Air condition level Condition number Number of microphones Number of sessions Number of files Remarks
0 km/h 1 00_00 31 1 31 None
  4 01_00 31 1 31 None
  7 02_00 31 1 31 None
30 km/h 1 03_00 31 1 31 None
  4 04_00 31 1 31 None
  7 05_00 31 1 31 None
50 km/h 1 06_00 31 1 31 None
  4 07_00 31 1 31 None
  7 08_00 31 1 31 None
60 km/h 1 09_00 31 1 31 None
  4 10_00 31 1 31 None
  7 11_00 31 1 31 None
70 km/h 1 12_00 31 1 31 None
  4 13_00 31 1 31 None
  7 14_00 31 1 31 None
80 km/h 1 15_00 ... 15_01 31 2 31 None
  4 16_00 ... 16_01 31 2 31 None
  7 17_00 31 1 31 None
100 km/h 1 18_00 ... 18_01 31 2 31 None
  4 19_00 31 1 31 None
  7 20_00 31 1 31 None
120 km/h 1 21_00 31 1 31 None
  4 22_00 31 1 31 None
  7 23_00 31 1 31 None
150 km/h 1 24_00 ... 24_01 31 2 31 None
  4 25_00 ... 25_02 31 3 31 None
  7 26_00 ... 26_01 31 2 31 None
180 km/h 1 27_00 31 1 31 None
  4 28_00 31 1 31 None
  7 29_00 31 1 31 None
200 km/h 1 30_00 31 1 31 None
  4 31_00 31 1 31 None
  7 32_00 ... 32_01 31 2 31 None



Impulse Responses

Sources and sinks Headrest loudspeakers Mouth loudspeakers Standard car loudspekers
Standard car microphones 228 impules respones 114 impules respones 76 impules respones
Ear microphones 144 impules respones 72 impules respones 48 impules respones
